| Electrical Specifications 2 meter |
| Frequency Range: |
144 – 145 MHz |
| Free Space Forward Gain: |
16.1 dBi |
| Forward Gain 20m AGL |
20.9 dBi |
| Front to Back Ratio: |
35 dB |
| 3 dB Horizontal Beam-width: |
29.9° |
| Polarization: |
Horizontal |
| Nominal Input Impedance: |
50 Ohm |
| Maximum SWR at any freq.: |
< 1.2 |
| Maximum Power Input: |
1500 W |
| G/T |
-1.23 |
| Matching Method: |
Direct feed through current balun. |
| Connector: |
“N” |
| Mechanical Specifications 2 meter |
| Boom length: |
7.84 m |
| Boom: |
Tapered Boom 40×40, 30×30, 20×20 |
| Longest element: |
1.04 m |
| No. of elements: |
13 |
| Turning radius: |
4.7 m |
| Mounting Mast Diameter: |
43 – 70 mm 1-11/16″ – 2-3/4″ OD |
| Survival Wind Speed: |
160 km/h |
| Weight: |
10.2 kg |
